Electric Bicycle EM 02D

Availability:
Quantity:
Inquire Add to Basket

Electric Bicycle EM 02D
Electric Bicycle EM 02D
Electric Bicycle EM 02D
Electric Bicycle EM 02D
Electric Bicycle EM 02D
Electric Bicycle EM 02D

  • EM 02D

  • Luyuan or OEM

Model   NameEM 02D
Motor Power48V350W
Controller48V18A   sine wave　
Display BoardK6MS   LCD display/5 level
Battery48V10AH*2
    (Tesson 2500mah cell)
Charger54.6V   2A (UL certificate)
ThrottleWUXING   130X (LH)
PAS SensorSpeed   sensor(left hidden dual Hall sensor)


BrakeXD-E500   Hydralic disc brake
DerailleruShimano   TX50-7/trigger shifter
Fork SuspensionHydraulic   lockout
Wheel/rim sizeSEYOUN   26*2.1
Range/Speed 1150km/25kmph   by PAS
Range/Speed 290km/25kmph   by throttle
Loading75－100kgs


Frame materialAL6061
Body Size1850*690*1160mm
Wheelbase1200mm
Net Weight24-28kg
Battery Weight6kgs
Color option
Packing size1860*230*1100mm
Container QTY56pcs/168pcs
